Displayviews
Geographicallocation(latitudeandlongitude)
TheGeographicallocationinformationisprovidedinthe
NavigationFieldontheTitleBaratthetopoftheEK15
displaypresentation.
ProvidedthataGPSsystemisconnectedtotheEK15,
thiseldontheTitleBarwilldisplaythevessel'sgeographicalpositioninlongitudeand
latitude.
Relatedtopics
•Navigationdialogboxonpage176
Heading
TheHeadinginformationisprovidedintheNavigationFieldonthe
TitleBaratthetopoftheEK15displaypresentation.
ProvidedthattherelevantsensorisconnectedtotheEK15,thiseld
ontheTitleBarwilldisplaythevessel'scurrentheading.
Relatedtopics
•Navigationdialogboxonpage176
Speed
TheSpeedinformationisprovidedintheNavigationFieldontheTitle
BaratthetopoftheEK15displaypresentation.
ProvidedthataGPSorspeedlogsystemisconnectedtotheEK15,
thiseldontheTitleBarwilldisplaythevessel'scurrentspeed.
ThecommunicationwiththeexternalGPSsystemorspeedsensorissetupusingthe
NavigationbuttonontheSetupmenu.
Relatedtopics
•Navigationdialogboxonpage176
Depth
ThedepthinformationisprovidedintheNavigationFieldontheTitle
BaratthetopoftheEK15displaypresentation.
ThecurrentdepthforoneofthetransducersconnectedtotheEK15
isshown.
Temperature
ThetemperatureinformationisprovidedintheNavigationFieldonthe
TitleBaratthetopoftheEK15displaypresentation.
Notethattemperatureinformationcanonlybeprovidedifasuitable
sensorisconnectedtotheEK15system.
351718/C
111
