Displayviews

Minimizebutton

TheMinimizebuttonislocatedattherightsideoftheTitleBaratthetopof

theEK15presentation.

ClickthisbuttontominimizetheEK15displaypresentation.Thisisan

operatingsystemfunction.

Torestorethepresentationtoitsprevioussize,clicktheEK15buttonontheoperating

system'sStatusBar.

Resizebutton

TheResizebuttonislocatedattherightsideoftheTitleBaratthetopofthe

EK15presentation.

ClickthisbuttontochangethesizeoftheEK15displaypresentation.This

isanoperatingsystemfunction.

Torestorethepresentationtoitsprevioussize,clicktheResizebuttonagain.

Exitbutton

TheExitbuttonislocatedattherightsideoftheTitleBaratthetopofthe

EK15presentation.

ClickthisbuttontoclosetheEK15program.

ObservethededicatedproceduretopowerdowntheEK15system.

Relatedtopics

•PoweringdowntheEK15onpage22

351718/C

113
