Echogram;HorizontalAxistab
Purpose
TheHorizontalAxistabinthe
Echogramdialogboxallowsyou
tochoosethehorizontalscaleofthe
echogram.Thiscontrolshow“fast”
theechogrammovesfromright
towardsleftacrossthedisplay.
Important
Thechangesyoumakeherewill
bydefaultonlybeappliedtothe
currentlyselected“active”echogram
(identiedwithathickborder).If
youwishtoapplythechangesto
alltheotherechogramsofthesame
type(forexampleallbottomrelated
echograms),clickApplyToAll.
Parameters
1HorizontalAxis
Youcansetupthehorizontalspeedbasedonfourparameters.
•Distance
Thehorizontalscaleoftheechogramisbasedonsaileddistance.Choose
resolutionandunitswiththespinboxesprovided.
•Time
Thehorizontalscaleoftheechogramisbasedontime.Chooseresolutionand
unitswiththespinboxesprovided.
