Finaltestsandmeasurements

•Root

Therootfoldercontainslesusedbythebackupprogram,aswellasthelesthat

makestheUSBdevicebootable.

Creatingabackupimageofallthesonarsoftware

Purpose

Thisprocedureisusedwhenyouwishtocreatea

backupcontainingallthesoftwarelesontheSU90

computer.

Description

TheprogramusedtodothebackupisAcronisTrueImage.Thisprogramisprovidedon

theProcessorUnit.

Tocreatethebackupimage,youneedthebootableUSBmemorydeviceprovidedwith

theSU90.

Procedure

1BootthecomputerfromtheUSBmemorydevice.

ThisproceduredescribeshowtostartuptheSU90computerfromabootable

USBmemorydevice.

1ConnectacomputerkeyboardtooneoftheUSBconnectorsonthecomputer.

2Insertthebootablememorydevice(USBashdrive).

3PoweruptheProcessorUnitwiththefrontmountedon/offbutton.

4ObservethatthecomputerbootsfromtheUSBashdrive.

5IfthecomputerdoesstartfromtheUSBdisk,reboot,andpressF11toselect

bootdevice.

2StarttheAcronisTrueImageprogram.

3Ontherstpage,clickBackUp.

4Onthesecondpage,clickDiskandPartitionBackup.

5OntheTargetbackuparchivepage,clickCreatenewbackuparchive,thenclick

Browsetoselectthelocationofthebackuple.

Youarefreetochoosewheretoplacethebackuple.However,themediayou

choosemustbebootable.Westronglysuggestthatyoucreatearelevantbackup

folderontheUSBashdiskthatisalreadyinuse.

6ClickGeneratename.

7ClickthesmallarrowbuttonontherightsideoftheGeneratenamebutton,andadd

dateandtimetothelename.

8ClickOK→Next→Proceed.

9ClickShutdownthecomputerwhenbackupiscompleted.
