Simrad SU90 Installation Manual

SimradSU90
Systemunits
TheSimradSU90comprisesthefollowingunits.
Topics
•Colourdisplayonpage19
•ProcessorUnitonpage19
•OperatingPanelonpage19
•OperatingPanelpowersupplyonpage20
•Audioamplierwithloudspeakersonpage20
•TransceiverUnitonpage20
•HullUnitonpage20
•Transduceronpage21
Colourdisplay
AnycommercialcolourdisplaycanbeusedwiththeSimradSU90system.Thechosen
displaymustbedesignedformaritimeuse,anditmustmeettheminimumperformance
specications.
NotethatthecolourdisplayisnotastandardpartoftheSU90delivery.
ProcessorUnit
TheProcessorUnitisamarinecomputerbasedon
theMicrosoftWindows
®
XP
®
operatingsystem.Itis
designedforruggeduse.
Thecomputerisbasedonacommercialdesign,but
thesoftwareandhardwarehasbeenspeciedand
assembledspecicallyforSimradtosuittheSU90requirements.
ThecomputerholdsmultipleUSBportsforusewithfuturesoftwareupgrades.These
USBportswillalsoallowyoutoexportscreencapturesfromthesonar.
OperatingPanel
TheOperatingPanelcontainsallnecessarycontrol
functionsfornormaloperationoftheSU90.
Thecontrolsarearrangedinlogicalfunctiongroups,
thisgivesaclearandeasyoperation.
ThemajorityoftheSU90functionscanbeaccessed
usingthetrackballontheOperatingPanelandthemenusystemonthedisplay.You
canalsouseastandardcomputermouse.
381293/A
19
