6Weldtheinstallationtrunktoadoublingplate.
Thisdoublingplatemustbeatleast1.5timesasthickasthesurroundingshell
plating.Thedoublingplate’snaldimensionsmustbegovernedbytheapproved
installationdrawingssuppliedbytheshipyard.
7Stiffenthetrunkinboththefore-and-aftandathwartshipdirectionsbywelding
knee-platesbothtothetrunkandtothedoublingplate.
Mountingthetrunkextension
(CD015415-020)
Purpose
IfyouarereplacingaSimradSX90orSP90
sonarsystemwithanewSU90system,
youcanusetheexistingtrunk.However,
duetothelargertransducerontheSU90,a
dedicatedtrunkextensionmustbemounted
ontopofyouexistingtrunk.
Prerequisites
Theinstallationshipyardmustprepareand
provideallrelevantresources.
Note
Theinstallationshipyardmustprovideallnecessaryinstallationdrawings,andif
required,thesemustbeapprovedbytheapplicableauthorities.
Relatedtopics
•Preparationsonpage37
•Sonartrunkinstallationprinciplesonpage59
Procedure
1Cleanthetopoftheexistingtrunkthoroughly.
Makesurethatthesurfaceisplainanevenwithoutscratches,dentsorotherdamage.
2Cleanthetrunkextension.
3Placethegasket(O-ring)initsthreadatthetopoftheexistingtrunk.
4ApplyO-ringlubrication.
5Placethetrunkextensioncarefullyontopoftheexistingtrunk,andmountitwith
thebolts.
Useminimumtorque472Nm
58
381293/A
