Cablelayoutandinterconnections

Readthisrst!

Note

Itisveryimportantthatallcablesareproperlyinstalledandcorrectlyterminated.

Observetherelevantregulationsandworkstandards.Alwaysleaveenoughcableslack

closetosystemunitsandcabinetstoallowformaintenance.KongsbergMaritimewill

notacceptanyresponsibilityforerrors,malfunctionsordamagetosystemorpersonnel

causedbyimproperwiring.

ObserveBasiccablerequirementsonpage307.

Detailedinformationaboutcablespecications,terminationandconnectorsareprovided.

AllcablesareprovidedbyKongsbergMaritimeunlessotherwisespecied.Inorder

toprovideformaintenanceandtoallowforvibration,makesurethatsomeslackis

providedforallcables.

Adetaileddrawingforeachcableisprovided.Eachdrawingprovidesadditional

specications,andmay,whenapplicable,include:

•Requiredminimumspecications

•Connectionsateachend(includingreferencetothecorresponding:systemunit,

terminalboardidenticationandplug/sockettobeused)

•Correspondingterminations

•Numberofcores

Cablesfallintotwocategories.

•Systemcables:ThesecablesaresuppliedbyKongsbergMaritime.

•Shipyardcables:Thesecablesmustbeprovidedbytheshipyardperformingthe

installation,ortheshipowner.Itisveryimportantthatthecablesusedmeetthe

minimumspecicationsprovidedinthismanual.

KongsbergMaritimeacceptsnoresponsibilityfordamagetothesystemorreduced

operationalperformancecausedbyimproperwiring.

Formoreinformation,seethebasiccablerequirements.

Note

BeforeyoustarttheSU90cabling,ensurethatthemainscircuitbreakerforthesystemis

switchedoff.Observetherelevantproceduresforhealth,environmentandsafety.

Important

Allelectronicinstallationsandcorrespondingwiringmustbeinaccordancewiththe

vessel'snationalregistryandcorrespondingmaritimeauthorityand/orclassication

society.Ifnosuchguidelinesexist,werecommendthatDetNorskeVeritas(DNV)

ReportNo.80-P008«GuidelinesforInstallationandProposalforTestofEquipment»

isusedasaguide.

ObserveBasiccablerequirementsonpage307.
