Simrad SU90 Installation Manual

SimradSU90
ThesensorfortheelectronicstabilisationofthesonarbeamsishousedintheMotor
ControlUnit,whichismountedontheHullUnit.
Caution
Ifthetransducerhitslargerobjectsorbottom,thetransducershaftmaybe
bent,or-inworstcase-itcanbebrokenoff.Abrokentransducershaftwill
causewaterleakagethroughthetopoftheshaft.
Insuchcases,donotraisethetransducershafttoitsupperposition.
Topreventseriousdamage,youmusthaveawaterpumpandawarning
systeminthesonarroom.
Transducer
ThecylindricalTransducerallowsthesonarbeamtogivefull360degreescoverageof
thewatervolumefrom+10anddownto-60degrees.
Scopeofsupply
PleaseobservethestandardandoptionalpartsprovidedwiththeSimradSU90delivery.
Topics
•Mainunitsincludedwiththestandarddeliveryonpage21
•Additionalitemsonpage22
Relatedtopics
•Additionalrequireditemsonpage22
•Optionalitemsonpage25
Mainunitsincludedwiththestandarddelivery
Partnumber
Part/unitnameanddescription
SH8-203593
OperatingPanel
382924
ProcessorUnit
381908
TransceiverUnit
373017
SU92HullUnit(with4.6mtransducercable)
Note
ThestandarddeliveryincludesanSU92hullunitwith4.6mtransducercable.Other
hullunitsandcablelengthsareoptional.
Relatedtopics
•Additionalrequireditemsonpage22
•Optionalitemsonpage25
381293/A
21
