SimradSU90
Connectingtheaudiocablesforexternalpoweredspeakers
Purpose
Thisprocedureexplainshow
toconnectapoweredspeaker
systemtotheSU90.Theaudio
systemcomprisestwoloudspeakers
andapowersupply.Oneofthe
loudspeakersis“active”,itcontains
theamplier,andvariouscontrollers
forthesoundvolumeandquality.
The“active”loudspeakeralso
providesaheadphonessocket.
Cableidentier
Thiscableisoptional.Itisnotshownonthecableplan.
Relatedtopics
•Cableplanonpage93
•Listofcablesonpage95
•Mini-jacktophonoaudiocableonpage294
•Commercialpoweredspeakersystemonpage304
Procedure
1Connecttheaudiocable(mini-jackconnectorsoneachend)fromtheaudiooutput
socket(L)ontherearsideoftheProcessorUnit.
Theoutputsocketisidentiedwithagreenring.
2Connecttheotherendoftheaudiocabletotherelevantsocketontherearsideof
the“active”loudspeaker.
3Connectthe“passive”speakertotheoutputconnectorontherearsideofthe
“active”speaker.
4Connectthepowersupplytothesocketsontherearsideofthe“active”speaker.
116
381293/A
