Simrad SU90 Installation Manual

SimradSU90
Speedlog
Inordertooperatecorrectly,theSimradSU90requiresinputfromaspeedlog.Inmost
casesasuitablesensorisalreadyinstalledonthevessel.Adifferentialglobalpositioning
system((D)GPS)canalsobeused.
Speedloginterfaceparameters:
•Serialline:StandardNMEA0183telegramformat
Relatedtopics
•Connectingthespeedlogonpage142
•Conguringandtestingtheinterfacetothespeedlogonpage157
Coursegyro
Inordertooperatecorrectly,theSimradSU90requiresinputfromacoursegyro.Inmost
casesasuitablesensorisalreadyinstalledonthevessel.
Coursegyrointerfaceparameters:
•Serialline:StandardNMEA0183telegramformat
Ifthecoursegyroinstalleddoesnotoutputthecorrectserialinterfaceformat,anoptional
gyrointerfaceboxisavailable.Itwillconvertthefollowingsynchroandstepping
gyrosignals:
•3-phasesynchrosignal,20to150VL-L,50/60/400Hz,gearration1:360or1:180
•3-phasesteppersignal,20to150VL-L,gearration1:360or1:180
Orderinginformation
LR40Gyrointerface
298-078535
Relatedtopics
•Connectingthecoursegyroonpage143
•Conguringandtestingtheinterfacetothecoursegyroonpage158
24
381293/A
