Simrad SU90 Installation Manual

SimradSU90
ConnectingthevideocablefromtheProcessorUnittothe
colourdisplay
Purpose
Thisisastandardcommercialcable.
Itisoftenphysicallyattachedto
thedisplay,andterminatedinthe
“computerend”withamaleDVI
connector.Thegraphicadapteron
therearsideoftheProcessorUnit
providestwoDVIconnectors,one
forHMDIandtwoforDisplayPort.
Choosetheconnectorthattsyour
cable.Ifyouhavetwodisplaysboth
canbeconnectedsimultaneously,but
theywillshowthesamepicture.
Cableidentier
ThisiscableSU90/C09.
Relatedtopics
•Cableplanonpage93
•Listofcablesonpage95
•DVI–IDisplaycableonpage303
•SVGAdescription(http://en.wikipedia.org/wiki/SVGA)
•HDMIdescription(http://en.wikipedia.org/wiki/HDMI)
•DisplayPortdescription(http://en.wikipedia.org/wiki/DisplayPort)
Procedure
1Connectthedisplaycablefromtheappropriateslot(s)ontherearsideofthe
ProcessorUnittothecolourdisplay.
Ifyouonlyconnectonedisplayisused,usethesocketonslotB.
Important
Keepthedisplaycableasshortaspossible.Ifthecableistoolong,itmaypickup
electricnoise,andthiswillreducetheimagequality.
102
381293/A
