Simrad SU90 Installation Manual

SimradSU90
Mainspecicationsforeachmodel
Parameter
SU92SU93
No.ofangebolts
2424
FlangeboltsPCD
680mm680mm
Trunkorderno.
SP9-207516SP9-207516
Unpackingthehullunitfromitstransport
box
Purpose
Thisprocedureexplainshowtounpackthehullunitfromitstransportbox
Note
Thetransducerisprotectedwithathicklayeroffoamtopreventdamageduring
transportandhullunitinstallation.Thisprotectionmustremainattachedwhilethehull
unitisbeingmanoeuvredintothesonarroom.
(CD015412-009)
B B
C
A
ALiftingeyeonthehoistingunit
BMountinghardware(woodencradleandsupportconstruction)
CTransducerprotection(thickfoam)
Procedure
1Removethetopcoverofthewoodentransportbox.
[_____]Ok
2PulloutallthenailsmarkedwithIndianink.
[_____]Ok
3Removethefasteninghardware(B).
[_____]Ok
68
381293/A
