Preparations

Athwartshipslocation

ThehullunitmaybelocatedontheCentreLine(CL)ofthevessel,oralongsideitskeel.

Note

Iftheinstallationisoffsetfromthevessel’ scentreline,makesurethattransducer

transmissionandreceptionwillnotbeobstructedbythekeel.

Importantconsiderationsrelatedtonoise

Theinstallationtrunkmustbeinstalledsothatitwillremainverticalundernormal

operatingconditions.Theprimarysourcesofunderwaterdisturbance(otherthana

vessel’smainpropellerandbow/sternthruster)thataffectSU90receptionare:

•Mainorbilgekeels

•Zincanodes

•Coolingelementsprotrudingfromthehull

•Equipmentsuchassonartransducersandpilottubes

•Seachests

•Overboarddischarges

•Dentsinthehull

Allappendagestothehull,indentationsandpipein/outletsarepotentialsourcesof

underwaternoise.Theymayactasresonantcavitiesamplifyingnoiseatcertain

frequencies,createcavitationorturbulence.Transducersshouldnotbelocatedinthe

vicinityofsuchobjectsandespeciallynotimmediatelyaftofthem.

Relatedprocedures

•Acousticnoiseonpage47

381293/A
