SimradSU90
ConnectingACmainstotheHeatExchanger
Purpose
ThisisastandardACmainscable.Oneendisalreadyterminatedontheheatexchanger.
TheotherendisterminatedinanACconnectorsuitableforthelocalconditions.Ifthisis
notthecase,youmustreplacetheACconnector.Thetypicalcablelengthisbetween1,5
and2meters.Ifthisistooshortyoumustuseanextensioncable(notrecommended),
mountanewpoweroutletwithinrange,ormakeyourownpowercable.
Cableidentier
ThisiscableSU90/C15
Note
ThemainsvoltagefortheHeatExchangeriseither230V acor115V ac.Makesurethat
youhavethecorrectmainsvoltage.TochecktheratedpowerfortheHeatExchanger ,
seetheregistrationlabelonthefrontoftheunit.
Relatedtopics
•Cableplanonpage93
•Listofcablesonpage95
•ACmainswithIEC60320socketandinlineplugonpage296
Procedure
1ConnecttheACmainscableontheHeatExchangertotheUninterruptedPower
Supply(UPS)inthesonarroom.
114
381293/A
