Simrad SU90 Installation Manual

Cablelayoutandinterconnections
ConnectingtheUSBcablefromtheOperatingPaneltothe
ProcessorUnit
Purpose
Thisprocedureexplainshowto
connecttheUSBcablefromthe
OperatingPaneltotheProcessor
Unit.
ThisisastandardcommercialUSB
datacable.Thecablelengthis4,5
meters.IthasaquadraticUSB
connectorintheOperatingPanel
end(B-plug),andrectangularUSB
connectorintheProcessorUnitend
(A-plug).
Cableidentier
ThiscableSU90/C10.
Relatedtopics
•Cableplanonpage93
•Listofcablesonpage95
•UniversalSerialBus(USB)on
page302
Procedure
1Connectthecablefromthe
B-typeUSBconnectorundertheOperatingPanel(B)totheUSBconnectoron
therearsideoftheProcessorUnit(H).
2SecuretheconnectorundertheOperatingPanelwithacablestripasindicated
withthe(C).
381293/A
103
