Simrad SU90 Installation Manual

Interfacingperipheralequipment
OpeningtheInstallationmenu
Purpose
ThisprocedureexplainshowtoopentheInstallationmenuontheSU90ProcessorUnit.
Procedure
1ClicktheSetuptabonthe
righthandsidetoopentheSetupmenu.
2ClicktheTestbuttontoopentheSystemTestmenu.
3ClicktheInstallationMenubutton.
4ObservethattheInstallationmenuappearsatthetopofthedisplay.
Conguringandtestingtheinterfacetothemotionreference
unit
Purpose
Observethefollowingproceduretosetupandtestthe
interfacewiththeexternalmotionreferenceunit.
Prerequisites
Thevesselmustbestableandnotmoving.Itmusttherefore
belocatedalongsidethequayorindrydock.
Relatedtopics
•MonitoringthetrafconaserialorEthernetlineon
page132
Procedure
1OpentheSetupmenu,andclickTesttoopentheSystemtestmenu.
2Readtheinformationfromtheinternalsensorinthetworollandpitch‘buttons’,
andwritedownthevalues.
3OpentheInstallationmenuasdescribedinOpeningtheInstallationmenuon
page145.
4ClickI/OSetup→Sensors→Stabilization→External.
5ObservethattheSensorCongparameterdialogappearsatthebottomofthemenu
eld.
6ChangethesettingsintheSensorCongparameterdialogtosuityourrequirements
fortheinterface.
aSpecifywhichcommunicationportyouhaveused.
bSpecifythecommunicationparametersfortheselectedport.
cSpecifythetime-outvalue.
dSpecifyiftheinputshallbeautomaticorxed.
381293/A
145
