Simrad SU90 Installation Manual

Drawingle
Drawingle
Thischaptercontainsrelevantdrawingsrelatedtotheinstallationandmaintenanceof
theSimradSU90.
Note
Thesemechanicaldrawingsareforinformationandguidanceonly.Theyarenotin
scale.Alldimensionsareinmmunlessotherwiseisnoted.Theoriginalinstallation
drawingsareavailableonPDFand/orAutoCad'sDWGformat.
Todownloadtherelevantinstallationdrawings,visithttp://www.simrad.com/su90
Topics
•Cabinetoutlinedrawingsonpage256
–TransceiverUnitdimensionsonpage257
–ProcessorUnitdimensionsonpage260
–OperatingPaneldimensionsonpage261
•HullUnitdrawingsonpage262
–SU92Hullunitdimensionsdrawingonpage263
–SU93Hullunitdimensionsdrawingonpage265
–SU92/SU93Mountingtrunkproductiondrawingonpage267
–SU92/SU93Extensiontrunkproductiondrawingonpage269
–SU92/SU93Blindcoverdrawingonpage271
381293/A
255
