Interfacingperipheralequipment

6ClicktheOffsetbutton.

7Entertheestimatedoffsetangle.

8ClickClosetosavetheoffsetangleandclosetheparameterdialog.

[_____]Ok

ConnectingasecondaryOperatingPanel

AsecondaryOperatingPanelmaybeconnected

totheSU90ProcessorUnit.Thismaybeusefulin

conjunctionwithasecondarydisplayifyouwishto

controltheSU90fromtwodifferentlocationsonyour

vessel.

Thesecondaryoperatingpanelwillallowyoutodoallsonaroperationsexcept

power

on/off.

Orderinginformation

SecondaryOperatingPanel(kitwithallparts)

372980

ThissectiondescribeshowtoinstallandconnectthesecondaryOperatingPanelto

theSU90system.

Topics

•PartsandtoolsrequiredtoinstallasecondaryOperatingPanelonpage147

•PhysicalinstallationoftheOperatingPanelonpage148

•InstallationoftheOperatingPanelcablesonpage148

•OpeningtheInstallationmenuonpage149

•ConguringandtestingtheinterfacetothesecondaryOperatingPanelonpage150

•CableplanforasecondaryOperatingPanelonpage151

•ListofcablesrequiredforthesecondaryOperatingPanelonpage152

PartsandtoolsrequiredtoinstallasecondaryOperating

Panel

YouneedthefollowingtoolsandequipmenttoinstallandconnectasecondaryOperating

Panel.

•Standardtoolsetforelectroniccables

•Keyboard

•Mouse

•HighqualityEthernetcable(minimumCAT5E)

•RJ45plugs

•SecondaryOperatingPanelkit[372980]comprisingthefollowingitems:

1[SH8–203593]OperatingPanel,complete

381293/A

147
