SimradSU90
StartinguptheSU90system
Todothenaltests,thevesselmustbeinthesea.Thisisbecausethetransduceralways
mustbeinwaterbeforeyoustarttransmitting.
Thefollowingsetofproceduresrequirestwopersons:
Onepersonmustbestationedonthebridgetooperatethesonar.
OnepersonmuststayinthesonarroomtomakesuretheTransceiverUnitworks
properly.
Thefollowingtwoproceduresmustbeperformedsimultaneouslybythepersononthe
bridgeandthepersoninthesonarroom:
Actionsonthebridgeshallbeperformedonthebridge.
Actionsinthesonarroomshallbeperformedinthesonarroom.
Tosimplifythetest,youmaybringacopyoftheapplicablepagesfromthismanual
downtothesonarroom.
Important
Makesurethatpropercommunicationexistsbetweenthetwobridgeandthesonarroom.
Note
Shouldproblemsoccurinthesonarroom,thepersoninthesonarroommustsetthe
serviceswitchS1onthePSUMainpowersupplyto“Off”(middleposition).
WARNING
Ifthesonarsystemstartstransmittingwhilethetransducerisin
openair,thismayleadtoseriousdamagetothetransducerand
thetransmitters.
Topics
PreparationsbeforetheSU90systemisstartedonpage190
StartinguptheSU90system,bridgeactionsonpage191
StartinguptheSU90system,sonarroomactionsonpage192
PreparationsbeforetheSU90systemisstarted
Purpose
Inordertopreparethesystemstart-up,carryoutthefollowingoperationsinthe
TransceiverUnitandtheMotorControlUnit.
190
381293/A
