Settingtowork

Startingupthebridgeunits

Observetheseproceduresthatstartthebridgeunitsforthersttime.

Note

InordertopreventinadvertentuseoftheSU90,theACmainsplugmustbedisconnected

whenthevesselisindrydock.Operatingthesonarwiththetransducerinairmay

causeseriousdamagetothesystem.

Topics

•StartingupoftheProcessorUnitforthersttimeonpage173

•Settingupthesonartoretrievesimulatedsonarechoesonpage174

•OpeningtheInstallationmenuonpage174

StartingupoftheProcessorUnitforthersttime

Purpose

ObservethefollowingproceduretostartuptheSU90forthersttime.Notethatthe

start-upprocedurefordailyuseisdescribedintheoperatorandreferencemanuals.

Procedure

1ConnecttheACmainsplugtotheProcessorUnit,andensurethat115or230Vacis

present.

[_____]Ok

2Locatethepowerswitchontherear(orfront)sideoftheProcessorUnit,and

switchpoweron.

[_____]Ok

3Powerupthecolourdisplay.

[_____]Ok

4PressthePowerbuttonontheOperatingPanelforapproximatelytwosecondsto

startthesonar.

[_____]Ok

5ObservethatthegreenLEDnexttothePowerbuttonontheOperatingPanelstarts

blinking.

Thesonarisnowloadingupthesonarprogram.Afterapproximatelyoneminute,

thesonarmenuwillbedisplayed.

[_____]Ok

381293/A

173
