Simrad SU90 Installation Manual

Interfacingperipheralequipment
•OperatingPanel“Dual”cableonpage306
•MoxaCP114EL-ISeriallineadapteronpage292
Procedure
1ConnectthefollowingcablesforthesecondaryOperatingpanel.
aConnectthedualserialcablefromthesecondaryOperatingPaneltothe
OperatingPanelPowerSupplyandtheRS–232extender.
bConnectthesingleUSBcablefromtheUSBsocketunderneaththesecondary
OperatingPaneltotheUSBextender.
cConnectthetwoCAT5–E(orbetter)Ethernetcablestothetwoextenders.
2ConnectthefollowingcablesbehindtheProcessorUnit.
aConnecttheUSBcablefromtheUSBextendertoavacantUSBsocketon
therearsideoftheProcessorUnit.
bConnecttheseriallinecablefromtheRS-232extendertoCOM2onslotDon
therearsideoftheProcessorUnit.
Usetheserialinterfaceadapterprovidedfortheplug.
3Connectallpowersupplies.
4ObservethededicatedproceduretosetuptheSU90software.
→ConguringandtestingtheinterfacetothesecondaryOperatingPanelon
page150
OpeningtheInstallationmenu
Purpose
ThisprocedureexplainshowtoopentheInstallationmenuontheSU90ProcessorUnit.
Procedure
1ClicktheSetuptabonthe
righthandsidetoopentheSetupmenu.
2ClicktheTestbuttontoopentheSystemTestmenu.
3ClicktheInstallationMenubutton.
4ObservethattheInstallationmenuappearsatthetopofthedisplay.
381293/A
149
