Simrad SU90 Installation Manual

AppendixCSU90cabledetails
DVI–IDisplaycable
ThiscableisastandardDVI-Icable.Itisnormallyprovidedwiththecolourdisplay.
C1
C2
C4C3
1 2
3
4
5
6 7 8
9
17
10
18
11
19
12
20
13
21
14
22
15
23
16
24
C5
Pin-out viewedfromthesocket
(CDC508)
PinSignalPinSignal
1
TMDSData2-(Digitalred-(Link1))
15
Ground(Returnforpin14andanalogsync)
2
TMDSData2+(Digitalred+(Link1))
16
Hotplugdetect
3
TMDSData2/4shield
17
TMDSdata0-(Digitalblue-(Link1)and
digitalsync)
4
TMDSData4-(Digitalgreen-(Link2))
18
TMDSdata0+(Digitalblue+(Link1)and
digitalsync)
5
TMDSData4+(Digitalgreen+(Link2))
19
TMDSdata0/5shield
6
DDCclock
20
TMDSdata5-(Digitalred-(Link2))
7
DDCdata
21
TMDSdata5+(Digitalred+(Link2))
8
Analogverticalsync
22
TMDSclockshield
9
TMDSData1-(Digitalgreen-(Link1))
23
TMDSclock+(Digitalclock+(Links1&
2))
10
TMDSData1+(Digitalgreen+(Link1))
24
TMDSclock-(Digitalclock-(Links1&
2))
11
TMDSData1/3shield
C1
Analogred
12
TMDSData3-(Digitalblue-(Link2))
C2
Analoggreen
13
TMDSData3+(Digitalblue+(Link2))
C3
Analogblue
14
+5Vdc(Standbypower)
C4
Analoghorizontalsync
TMDS=TransitionMinimizedDifferential
Signaling
C5
Analogground(ReturnforR,GandB
signals)
Cablespecications
•Notapplicable.Thisisacommercialcable.
Relatedtopics
•http://en.wikipedia.org/wiki/Digital_Visual_Interface
•Listofcablesonpage95
•ConnectingthevideocablefromtheProcessorUnittothecolourdisplayonpage102
381293/A
303
