SimradSU90

Cableprocedures

ObservethefollowingprocedurestodotheSU90cabling.

1Detailedinformationaboutcablespecications,terminationandconnectorsare

providedinthereferenceddrawings.

2AllcablesareprovidedbySimradunlessotherwisespecied.

3Inordertoeaseaccessformaintenancepurposes,andtoallowforvibration,make

surethatsomeslackisprovidedforeachcable.

4BeforeyoudotheSU90cabling,ensurethatthemainscircuitbreakersareswitched

off.

5DonotmounttheexibletransducercabletotheTransceiverUnit.Thiswillbe

describedlater.

Topics

•ConnectingACmainstotheUninterruptedPowerSupplyonpage101

•ConnectingthevideocablefromtheProcessorUnittothecolourdisplayonpage102

•ConnectingtheUSBcablefromtheOperatingPaneltotheProcessorUniton

page103

•ConnectingthedualinterfacecablefromtheOperatingPaneltotheProcessorUnit

onpage104

•ConnectingtheOperatingPanelPowerSupplytotheProcessorUnitonpage105

•ConnectingACmainsandgroundtotheProcessorUnitonpage106

•ConnectingACmainstothecolourdisplayonpage107

•ConnectinggroundtotheOperatingPanelonpage108

•ConnectingtheProcessorUnittotheTransceiverUnitonpage109

•ConnectingACmainstotheTransceiverUnitonpage111

•ConnectingACmainstotheMotorControlUnitonpage112

•ConnectingtheTransceiverUnittotheMotorControlUnitonpage113

•ConnectingACmainstotheHeatExchangeronpage114

•ConnectingtheEthernetcableforscienticoutputonpage115

•Connectingtheaudiocablesforexternalpoweredspeakersonpage116

•Connectingthetransducercableonpage117

•Connectingtheinterfacecablestotheperipheralequipmentonpage117

100

381293/A
