Cablelayoutandinterconnections
ConnectingtheEthernetcableforscientiîš¿coutput
Purpose
ThisisanEthernetcable.Itmustbe
providedbytheinstallationshipyard.
Useacommercialhighquality
Ethernetcablesuitabletomatchthe
bandwidthontheship'snetwork.
Cableidentiîš¿er
ThisiscableSU90/C14.
Relatedtopics
•Cableplanonpage93
•Listofcablesonpage95
•RJ45Ethernet,straighton
page300
Procedure
1ConnecttheEthernetcablefromtheadditionalEthernetsocketontherearside
oftheProcessorUnit.
2TerminatetheotherendoftheEthernetcableinasuitableaccesspointforthe
ship'snetwork.
381293/A
115
