Simrad SU90 Installation Manual

Interfacingperipheralequipment
Overviewofinterfacesandsupported
telegramformats
Thefollowingsectionssummarizetheinputandoutputtelegramssupportedbythe
SU90,aswellastheoptionontheInstallationmenuusedtoactivatethem.
Topics
•Telegramsreceivedfromexternaldevicesonpage125
•Telegramssenttoexternaldevicesonpage127
Telegramsreceivedfromexternaldevices
Onlysystemsthatsupportinputtelegramsfromexternalsensorsarelisted.Remaining
choicesontheInstallation→I/OSetupmenuareforinternalorspecialinterfaces.
Trawlsystem
Path:Installationmenu→I/OSetup→Sensors→Trawlsystem
•SimradITI
–TPTTrawlpositiontruevesselonpage248
–TPCTrawlpositionincartesiancoordinatesonpage247
–GLLTrawlpositiononpage242
–DBSDepthoftrawlbelowsurfaceonpage242
–MTWWatertemperatureatthetrawlonpage244
–HFBTrawlheadropetofootropeandbottomonpage243
–TDSTrawldoorspreadonpage246
–TS2Trawlspread2onpage248
–TFITrawlllingonpage247
–TTSTrawltoshoaldistanceonpage248
–HDMHeading,magneticonpage237
–HDTHeading,trueonpage237
–TPPTrackedtargetpositionormarkeronpage247
•SimradFS3300
–FS3300Binarydepthonpage242
–DBSDepthbelowsurfaceonpage234
Note
TheGLLtelegrammaybereceivedfromintegratedinstrumentsusingthe“ii”talker
identier.TheSimradITIsystemusesthesametalkeridentier“ii”,andthishascaused
someconfusionforsomeofourusers.Inordertorectifythis,theITIGLLtelegram
hasbeeninhibited.
381293/A
125
