SimradSU90
MoxaCP114EL-ISeriallineadapter
TheProcessorUnitisequippedwithaMoxaCP114EL–Iserialadapterboard.Each
boardprovidesfourseriallines.Theconnectionstotheboardaremadeusingfour9–pin
D-connectors,andshortconvertercablesareprovidedwiththeboard.
Cablespeciîš¿cations
•Conductors:5x2x0.5mm²
•Screen:Screenedtwistedpairsandoverallbraided
•Voltage:60V
•Maximumdiameter:Limitedbytheplugs
292
