Cablelayoutandinterconnections

ConnectingtheOperatingPanelPowerSupplytothe

ProcessorUnit

Purpose

Inordertofacilitatethesonar'son/off

function,theOperatingPanelmust

befedapermanentstand-bypower.

Thissupplypowerisprovidedby

asmallcommercialpowersupply

connectedtotherearsideofthe

ProcessorUnit.IftheACmains

connectoronthecabledoesnott,

replaceitwithasuitableconnector.

ThemainsvoltagefortheOperating

PanelPowerSupplyis115or230

Vac,anditwillautomaticallysensethecurrentsupplyvoltage.

Cableidentiers

TheACmainscableisSU90/C05,whiletheDCendisSU90/C04.

Relatedtopics

•Cableplanonpage93

•Listofcablesonpage95

•ACmainswithIEC320/C7inlineplugonpage298

•OperatingPanelpowersupplyonpage299

Procedure

1Securethepowersupplyunitinastableposition.

2ConnectthepowersupplytotheACmainsusingthecableprovided.

3InserttheDCplugintothesocketontheappropriatecircuitboardontherearside

oftheProcessorUnit.

ThecircuitboardislocatedinslotG.

4Securethecablestopreventthemfromaccidentallydisconnectingduringheavy

seas.

381293/A

105
