Simrad SU90 Installation Manual

Settingtowork
EnteringthestabilisationoffsetangleintotheSU90
Purpose
Oncetheoffsetanglehasbeenmeasured,itmustbeentered
intotheSU90setupparameters.
Procedure
1OpentheSetupmenu.
2ClicktheTestbuttontoopentheSystemtestmenu.
3ClicktheInstallationMenubutton,andobservethemenu
thatappearsonthetopofthedisplay.
4SelectInstallation→Installation→Alignment.
5ObservethattheSonar
transceiverconguration
parameterdialogappearsat
thebottomofthemenueld.
6ClicktheOffsetbutton.
7Entertheestimatedoffsetangle.
8ClickClosetosavetheoffsetangleandclosetheparameterdialog.
[_____]Ok
Deningownshipparameters
Inordertoachieveaccuratereadingsfromthesonarsystem,certainvesselparameters
mustbeentered.
Topics
•Specifyingshipdimensionsonpage195
•Specifyinginstrumentpositionoffsetsonpage196
•OpeningtheInstallationmenuonpage196
Specifyingshipdimensions
Purpose
Togetthecorrectsizeofthevesselsymbolonthedisplay,
thelengthandwidthofthevesselmustbeidentied.
Procedure
1OpentheInstallationmenu.
→OpeningtheInstallationmenuonpage196
2SelectInstallation→Ownship→Shipdimensions.
3ObservethattheShipDimensionsparameterdialog
appearsatthebottomofthemenueld.
381293/A
195
