Simrad SU90 Installation Manual

SimradSU90
•Ifafourthtargetisselected,theinformationabouttherst(oldest)targetis
disabled.
7A=status,charactersV(datavalid)orN(datanotvalid)areused.
8llll.lll,a=target'slatitudepositionnorth/south.CharactersN(North)orS(South)
identiesthebearing.
9yyyyy.yy,a=target'slongitudepositioneast/west.CharactersE(East)orW(West)
identiesthebearing.
10xxx(+),M=horizontalrange,meters,emptydenominationeld(,,)indicatesan
invalidvalue.Notethatthiseldhasavariablelengthwithminimumthreedigits.
11ppp,P=directiontotargetrelativetonorth,degrees,emptydenominationeld
(,,)indicatesaninvalidvalue
12zzz(+),M=depth,meters,emptydenominationeld(,,)indicatesaninvalidvalue.
Notethatthiseldhasavariablelengthwithminimumthreedigits.
13vvv.v,N=target'sspeed,knots,emptydenominationeld(,,)indicatesaninvalid
value
14ttt,D=target'scourse,degrees,emptydenominationeld(,,)indicatesaninvalid
value
15www(+),A=area,squaremeters,emptydenominationeld(,,)indicatesaninvalid
value.Notethatthiseldhasavariablelengthwithminimumthreedigits.
16ddd(+),A=volume,tons,emptydenominationeld(,,)indicatesaninvalidvalue
Notethatthiseldhasavariablelengthwithminimumthreedigits.
MTWWatertemperatureatthetrawl
ThisproprietarySimradtelegramcontainsthewatertemperaturemeasuredbythetrawl
sensor.
Format
$IIMTW,xx.x,C<CR><LF>
Formatdescription
1II=talkeridentier(mandatory)
2MTW=telegramidentier
3xx.x,C=watertemperature,degreesCelcius
PSIMP-DPISensordata
ThisproprietarySimradtelegramcontainsthetypeandcongurationofPSandPI
sensorsusedbytheexternalPIcatchmonitoringsystem.
Note
Thistelegramformatisnolongerinuse.IthasbeenreplacedbyPSIMP-D1.The
descriptionisnotcomplete.Forfurtherinformation,contactSimrad.
244
381293/A

Simrad SU90 Specifications

General

Brand	Simrad
Model	SU90
Category	Sonar
Language	English
