Simrad SU90 Installation Manual

SimradSU90
C13SU90/C12USBcable
ThiscableisprovidedwiththeUSBextender.ItisastandardUSBdatacable.
C14SU90/C14Ethernetcable
Thiscablemustbeprovidedbytheclientortheinstallationshipyard.Maximum
lengthis100m.UseminimumcablequalityCat5–E.
→RJ45Ethernet,straightonpage300
C15SU90/C15Ethernetcable
SameasC14.
Establishingemergencyhoistfunctionality
Thissectiondescribeshowtousetheemergencyhoistfunctionalityprovidedbythe
SU90.
Note
TheemergencyhoistfunctionalityisprovidedbytheHullUnitControlcircuitboardin
theMotorControlUnit.Simraddoesnotofferanyoptionalproductsorkitstoput
thisfunctionalitytouse.Anyapplicationsthattheenduserwishtoestablishmustbe
designedandmanufacturedbasedontheinformationprovidedinthissection.
Topics
•Designingtheemergencyhoistinterfaceonpage154
•Circuitboardinterfacedescriptiononpage155
Designingtheemergencyhoistinterface
Purpose
Thisprocedureexplainsthebasicstepsrequiredtousetheemergencyhoistfunctionality
providedbytheSU90.
Prerequisites
Inordertousetheemergencyhoistfunctionalityyouwillneedtodesignyourown
interfaceapplication.Youwillalsoneedtopurchasetheplugthattstheinterface
connectorontheHullUnitControllercircuitboard.
Procedure
1Designtheemergencyhoisthardwaresystemaccordingtotheinterfacedescription
provided.
→Circuitboardinterfacedescriptiononpage155
2ObtaintheplugthattstheP9connectorontheHullUnitControllercircuitboard.
→Circuitboardinterfacedescriptiononpage155
154
381293/A
