AppendixCSU90cabledetails
GenericRS-232Serialline(Threewires)
Thiscableholdsamultipurposeserialline.Itprovidesinterfacewithanyperipheral
unit.Oneendofthecableconnectstothelocalunit(DTE)witha9-pinD-connector,
whiletheotherconnectstotheperipheral(DCE)asdescribedintheperipheralunit’s
documentation.Notethatthiscabledoesnotsupportallthesignalsinthestandard
RS-232speciîš¿cation.
Local
9-pin ‘D’ connector
Remoteî˜ system
9-pin ‘D’ connector
9 6
Femaleî˜ 9-pin
D-pinî˜ connector
1
5
Maleî˜ 9-pin
D-pinî˜ connector
5
1
6 9
2
3
5
RX
GROUND
2
3
5
TXTX
GROUND
RX
View
(CDCî˜ 103)
Cablespeciîš¿cations
•Conductors:3x0.5mm²
•Screen:Overallbraided
•Voltage:60V
•Maximumcablediameter:Limitedbytheplugs
Relatedtopics
•RS-232onWikipedia
•Listofcablesonpage95
381293/A
289
