Simrad SU90 Installation Manual

SimradSU90
Optionalitems
Thefollowingoptionalequipmentandfunctionalitymaybeorderedatanadditional
chargetoaugmentthestandardSimradSU90systemdelivery,orpurchasedlocally
bytheinstallationshipyardorenduser.
Topics
•Installationtrunkonpage25
•Extendedrangeonpage26
•Scienticinterfaceonpage26
•Otherperipheralequipmentonpage26
•Audiooutputonpage28
•Externalmotionreferenceunit(MRU)onpage30
•SecondaryOperatingPanelonpage30
Hullunit
ThestandardSU92HullUnitcanbelowered1.2metersataspeedof21knots.The
mountingangehas24boltswithpitchcentrediameter(PCD)680mm.Otherhull
unitsareavailableaslistedbelow.
HullunitsavailablefromKongsbergMaritime
HullUnitSpecicationsOrderno.
SU92*1.2m,21knots,24bolts,PCD680mm,4.6mtransducercable
373017
SU92
1.2m,21knots,24bolts,PCD680mm,7mtransducercable
386420
SU93
1.6m,16knots,20bolts,PCD620mm,4.6mtransducercable
373018
SU93
1.6m,16knots,20bolts,PCD620mm,7mtransducercable
386422
(*=SU92with4.6mtransducercableisthestandardhullunit)
Installationtrunk
Theinstallationtrunkmaybefabricatedbytheinstallationshipyard,orsuppliedby
KongsbergMaritime.Thesameinstallationintrunkisusedforallhullunits.
IfyouarereplacinganSX90orSP90sonarwithanewSU90,youcanuseyourexisting
trunk.However,duetothelargertransducerontheSU90sonar,atrunkextensionmust
beused.
OptionalinstallationtrunksavailablefromKongsbergMaritime
Trunktype
SpecicationsOrderno.
SU92/SU9324bolts,PCD680mm
376655
Extension24bolts,PCD680mm
374676
Relatedtopics
•Mountingthetrunkextensiononpage58
381293/A
25
