Aboutthismanual

Purpose

Thepurposeofthismanualistoprovidetheinformationandbasicdrawingsrequiredfor

installationoftheSimradSU90.

Formoredetailedinformationaboutthepracticaluseoftheproduct,refertotheSimrad

SU90OperatormanualortheSimradSU90Referencemanual.

Targetaudience

Themanualisintendedfortechnicalpersonnel;qualiedmaintenanceengineersand

technicians.Itisassumedthatthepersonnelisconversantwiththegeneralprinciplesof

maritimeelectronicequipment,inparticularsonar,echosounderandcatchmonitoring

systems.Thepersonnelmustalsobefamiliarwithcomputerhardware,signalprocessing,

interfacetechnologyandtraditionaltroubleshootingonelectronicandmechanical

products.

WeassumethatyouarefamiliarwiththeWindows

and/orWindows

7operating

system,andconversantwithnetworkaddressingandcommunicationprinciples.

Installationinstructions

Theinstructionsprovidedinthismanualmustbefollowedcarefullytoensureoptimal

performance.Asaguide,installationproceduresarepresentedintheordertheyareto

beperformed.

Theequipmentdescribedinthismanualincludesthecompletesystemwithrelevant

cabinets,butnotsystemunitsprovidedlocallybythecustomer,installationshipyardor

localrepresentative.Themanualalsodenestheequipmentresponsibility,andprovides

applicableinstructionsforunpackingandstorage.

Note

Theinstallationinstructionsgiveninthisdocumentmustbeadheredto.Failuretodoso

mayrendertheguaranteevoid.

KongsbergMaritimeASwillacceptnoresponsibilityforanydamageorinjurytothe

system,vesselorpersonnelcausedbyequipmentthathasbeenincorrectlyinstalledor

maintained,orbydrawings,instructionsorproceduresthathavenotbeenprepared

byus.
