Settingtowork

Procedure

1Connectandfastenthetransducerplugtotheleft-handsideoftheTransceiverUnit.

Usethescrewsandwashersappliedfortheprotectingcover.

Note

Toavoidunnecessarystrainontheconnectors,youmustinsertthetransducerplug

straightin.Tightenthefasteningscrewsevenlyandalittleatatime,alternating

betweenscrewsonoppositesidesoftheplug,untilallthescrewsareadequately

tightened.

[_____]Ok

2Re-insertthefusesF1andF2ontheHighVoltagepowersupply.

TheHighVoltagepowersupplyistheunitmountedonthefarrightsideofthe

TransceiverUnit.

[_____]Ok

3Setthehoist/lowerswitchS302intheMotorControlUnittoRemoteposition.

[_____]Ok

StartinguptheSU90system,bridgeactions

Note

Thisproceduremustbeperformedsimultaneouslywiththenextprocedure;Startingup

theSU90system,sonarroomactionsonpage192.

Theinstructionsmarked[Sonarroom]aredoneinthesonarroom.

Purpose

ThisprocedureexplainstheactionstobemadeonthebridgewhentheSU90system

isstarted.

Procedure

1Startupthesonar.

[_____]Ok

2Checkthatthedepthissufcientforloweringofthetransducer.

[_____]Ok

3PresstheMiddlebuttonontheOperatingPaneltolowerthetransducertoitsmiddle

position.

[_____]Ok

4ClicktheModebuttononthetopofthemenusystem,andselectmodeBowup.

[_____]Ok

5OpentheHorizontalmenu,andlocatetheTXPowerbutton.

6SettheTXPowertoLow,andcheckthatechoesappearonthedisplay.

[_____]Ok

381293/A

191
