SimradSU90
Proprietarythirdpartytelegramsand
formats
AllthirdpartytelegramformatssupportedbytheSU90arespeciedhere.These
telegramformatsarecreatedbythirdpartyorganizations,andtheyaresupportedbythe
SU90toallowforinterfacetothirdpartysystems.
Topics
•FurunoCIFSeacurrentonpage250
•KaijoVDVCDV ectorcurrentdirectiononpage253
•RyokoseiRBYBuoyinputonpage253
•SerpeBSCBuoyinputonpage254
•FurunoCIFSeacurrentonpage250
•KaijoVDVCDV ectorcurrentdirectiononpage253
•RyokoseiRBYBuoyinputonpage253
•SerpeBSCBuoyinputonpage254
FurunoCIFSeacurrent
ThisproprietaryFurunotelegramformatisusedtocontaininformationaboutseacurrent.
Theoriginalsignalformatisa20mAcurrentloop,anditneedstobeconvertedto
RS-232.Theserialportmustthenbesetupusingdedicatedparameters.
SerialparametersforFurunoCIF
•4800baud
•Evenparity
•7databits
•1startbit
•2stopbits
Transmissionformat
Table10FurunoCIF ,Transmissionformat
ASCIIWidth
HEX
Comments
STX
1byte
0x02
Starttransmission
(Startloop)
Data
Refertothesentencedescriptions.Severalsentencesarecontainedwithinoneblock.
FS
1byte
0x1C
Fieldseparator
(Endloop)
FS
1byte
0x1C
Fieldseparator
ETX
1byte
0x03
Endtransmission
250
381293/A
