Theadvantageofthissetupisthatmoststereosystemsareprovidedwitharemote
control,andthisallowsforeasyadjustmentoftheaudiolevel.
Externalmotionreferenceunit(MRU)
Bydefault,theSU90usesabuilt-inmotionreferencedetectormountedonthehullunit.
Forimprovedaccuracy,andexternalmotionreferenceunit(MRU)maybeused.
ThemotionreferenceinterfacefunctionalityontheSU90hasbeendesignedtomatch
theMRUsmanufacturedbyKongsbergSeatex.Descriptionsofallavailabletypesare
providedonhttp://www.km.kongsberg.com/seatex
.TheMRUinterfaceintheSU90
willhoweverallowyouuseanytypeofsensorprovidedthatitoutputstheEM3000
datagramformat.
Relatedtopics
•Otherperipheralequipmentonpage26
•Connectinganexternalmotionreferenceunit(MRU)onpage144
SecondaryOperatingPanel
AsecondaryOperatingPanelmaybeconnected
totheSU90ProcessorUnit.Thismaybeusefulin
conjunctionwithasecondarydisplayifyouwishto
controltheSU90fromtwodifferentlocationsonyour
vessel.
Thesecondaryoperatingpanelwillallowyoutodoallsonaroperationsexceptpower
on/off.
Orderinginformation
SecondaryOperatingPanel(kitwithallparts)
372980
Relatedtopics
•ConnectingasecondaryOperatingPanelonpage147
30
381293/A
