Simrad SU90 Installation Manual

SimradSU90
Abouttheaudiooutput
Theaudiooutputmustthereforebeconnectedtoapoweredaudiosystem.Thesystem
mustincludeavolumecontrol,astheaudiooutputlevelfromthesonarisxed.The
audiooutputlevelcannotbecontrolledbytheAudiooffbuttonontheOperatingPanel,
asthisbuttonwillsilencetheaudiooutputcompletely.
Donotconnectaloudspeakerdirectlytotheaudiooutput.Thismaydamagetheaudio
outputcircuitry.
Werecommendthatoneofthefollowingaudiosystemsisused:
•CommercialpoweredspeakersystemforPCuse
•Commercialstereosystemwithamplierandtwo(ormore)loudspeakersand/or
headphones
PoweredspeakersystemforPCuse
AcommercialpoweredspeakersystemforPCusecanbeobtainedfromalmostanykind
ofshopforelectricappliances,homestereoorcomputers.
SIMRAD
PWR
MENU
SIMRAD
SIMRAD
(CD015043-021)
Thenumberofspeakers,sizeandpoweroutputcanbeselectedtosuitthecrew
preferences.Thelocationofthespeakersmustbedecidedtoallowforeasyadjustment
oftheaudiolevel.
Stereosystemwithamplierandtwoormoreloudspeakers
Ifastereosystemisalreadyinstalledonthebridge,theaudiooutputfromtheSU90
canbeconnectedtoanauxiliaryinput.
381293/A
29
