Simrad SU90 Installation Manual

Installingthehullunit
Hullunitmodelsoverview
SU90Hullunitmodels
SU92 SU93
(CD015404-030)
Twodifferenthullunitmodelsareavailable
fortheSU90sonar.TheseSU90hullunit
modelsarebasedonthesametransducer,
butwithdifferentstrokelengths.Inthis
manual,thesedifferencesarepointedout
wheneverapplicable.
TheSimradSU92isthestandardhullunit
providing1,2mstrokelength.TheSU93
istheoptional“long”versionoffering1,6
mstrokelength.
•SU92:Thisisthe"standard"hullunit
fortheSX90sonar.Ithas1.2mstroke
length,anditisdesignedformaximum
speed24knots.Itwilltonastandard
Simradtrunkwith680mmpitchcentre
diameter.
•SU93:Thishullunithas1.6mstroke
length,anditisdesignedformaximum
speed20knots.Itwilltonastandard
Simradtrunkwith680mmpitchcentre
diameter.
SU90hullunitmodelswith4.6metertransducercable
HullunitRegistrationnumberOrdernumber
SU92372968373017
SU93373015373018
Thelabelwiththeregistrationnumberislocatedonthesideofthegantry.
SU90hullunitmodelswith7metertransducercable
HullunitRegistrationnumberOrdernumber
SU92386419386420
SU93386421386422
Thelabelwiththeregistrationnumberislocatedonthesideofthegantry.
Mainspecicationsforeachmodel
Parameter
SU92SU93
Strokelength
1,2m1,6m
Maximumspeed24knots20knots
Flangediameter
761mm761mm
381293/A
