Simrad SU90 Installation Manual

SimradSU90
Note
Toextendthelifetimeoftheequipment,itisstronglyrecommendedtomounttheunitsat
dryandcleanlocationswithsufcientventilation.Observethesonarroomrequirements.
Colourdisplay
•ThecolourdisplayisnotapartoftheSimradSU90scopeofsupply.Refertothe
documentationprovidedbythemanufacturer.
ProcessorUnit
•Operatingtemperatures:-15to+55°C
•Storagetemperatures:-20to+70°C
•Relativehumidity:10to95%(non-condensing)
OperatingPanel
•Operationaltemperature:0to+50°C
•Storagetemperature:-40to+70°C
•Relativehumidity5to95%relativenon-condensing
OperatingPanelPowerSupply
•Operationaltemperature:0to+50°C
•Storagetemperature:-40to+70°C
•Relativehumidity5to95%relativenon-condensing
HullUnit
•Operationaltemperature:0to+50°C
•Storagetemperature:-20to+40°C
•Relativehumidity5to95%relativenon-condensing
Important
Thetransducermustnotbeexposedtodirectsunlightforalongperiodoftime.
Minimumdisplayrequirements
UnlessspecicallyorderedfromSimrad,theSU90isnotprovidedwithacolourdisplay.
Thisitemmustbepurchasedlocally.YoucanuseoneortwodisplaysoneyourSU90
computerdependingonpersonalandoperationalpreferences.
Itisimportanttomakesurethatthechosendisplaymodelmeetsthetechnicalsystem
requirements.Makesurethatthedisplaydesignandconstructionallowformarineuse,
easyaccesstocables,andasafeinstallation.
Theminimumrequirementsare:
•Resolution:Minimum1280x1024pixels.
224
381293/A
