Simrad SU90 Installation Manual

Cablelayoutandinterconnections
C18SU90/C183–phaseACpowertoMotorControlUnit
Thiscablemustbeprovidedbytheinstallationshipyard.ItisaspecialAC
mainscable.
Important
Youmustuseminimum4x2.5mm²cable.Ensurethatthescreenisproperly
terminatedinthecablegland.
DONOTapply3–phasepowertotheMotorControlUnituntilspecically
instructedbytherelevantprocedure.
→ConnectingACmainstotheMotorControlUnitonpage112
→3–phaseACmainstoMotorControlUnitonpage297
C19SU90/C19EthernetcablefromtheTransceiverUnittotheMotorControlUnit
ThisEthernetconnectionismadebetweentheTransceiverUnitandtheMotor
ControlUnit.ThiscableisprovidedwiththeSU90.
→ConnectingtheTransceiverUnittotheMotorControlUnitonpage113
→RJ45Ethernet,straightonpage300
C20SU90/C27Transducercable
ThistransducercableisprovidedwiththeSU90.Itcontainsonecablepairfor
eachofthetransceiverchannelsinaspecialscreenedcable.
Thetransducercableisphysicallyattachedtothetopofthetransducershaft,and
connectstoaspecialconnectoronthesideoftheTransceiverUnit.
Thelengthofthetransducercableis4,5meters.
Important
Donotconnectthetransducercableuntilspecicallyinstructedtodosobythe
relevantprocedure.
→Connectingthetransducercableonpage117
381293/A
99
