Simrad SU90 Installation Manual

SimradSU90
C14SU90/C14Ethernetinterfaceforscienticoutput(optional)
Thiscablemustbeprovidedbytheinstallationshipyard.
→ConnectingtheEthernetcableforscienticoutputonpage115
→RJ45Ethernet,straightonpage300
Note
ItisveryimportantthatahighqualityEthernetcableisused.Youmustuse
CAT-5Equalityorbetter.Cableswithlowerbandwidthcapacitywillreduce
theSU90performance.
C15SU90/C15ACmainstoUninterruptedPowerSupplyinthesonarroom
ThisisastandardACmainscable.ItisprovidedwiththeUninterruptedPower
Supply.ThepowersupplyendisnormallyterminatedwithanIECC13inline
socket.
TheotherendisterminatedinanACconnectorsuitableforthelocalconditions.
Ifthisisnotthecase,youmustreplacetheACconnector.Thetypicalcable
lengthisbetween1,5and2meters.Ifthisistooshortyoumustuseanextension
cable(notrecommended),mountanewpoweroutletwithinrange,ormakeyour
ownpowercable.
→ConnectingACmainstotheUninterruptedPowerSupplyonpage101
→ACmainswithIEC60320socketandinlineplugonpage296
C16SU90/C16ACmainstoTransceiverUnit
ThiscableisprovidedwiththeSU90.Itisastandardmainssupplycable.The
transceiverendisnormallyterminatedwithanIECC13inlinesocket.
TheotherendisterminatedinanACconnectorsuitableforthechosen
UninterruptedPowerSupply(UPS)system.Ifthisisnotthecase,youmust
replacetheACconnector.Thetypicalcablelengthisbetween1,5and2meters.
Ifthisistooshortyoumustuseanextensioncable(notrecommended),movethe
UPSunit(s)withinrange,ormakeyourownpowercable.
→ConnectingACmainstotheTransceiverUnitonpage111
→ACmainswithIEC60320socketandinlineplugonpage296
C17SU90/C17ACmainstoheatexchanger
ThiscableisprovidedwiththeSU90.ThisisastandardcommercialACmains
cable.Oneendisalreadyterminatedontheheatexchanger.
TheotherendisterminatedinanACconnectorsuitableforthelocalconditions.
Ifthisisnotthecase,youmustreplacetheACconnector.Thetypicalcable
lengthisbetween1,5and2meters.Ifthisistooshortyoumustuseanextension
cable(notrecommended),mountanewpoweroutletwithinrange,ormakeyour
ownpowercable.
→ConnectingACmainstotheHeatExchangeronpage114
→ACmainswithIEC60320socketandinlineplugonpage296
98
381293/A
