SimradSU90
Hullunitinstallationchecklist
Performaclosevisualinspectionofthesonarroomandthephysicalinstallationof
thehullunit.RefertotheapplicablerequirementsprovidedinsectionSonarroom
requirementsonpage42,andîš¿llinthetablebelow.
Item
YESNO
Aretheaccesshatchessatisfactoryconstructedandlocated?
Istheheatingsatisfactory?
Istheinsulationsatisfactory?
Istheventilationsatisfactory?
Isabilgepumpinstalled?
Istheroomlightingsatisfactory?
Isthesonarroomsuitablydecked?
Isthemechanicalsupportofthehullunitsatisfactory?
DoyouhavesatisfactoryaccesstotheMotorControlUnit?
Didthevisualinspectionofthetransducerconîš¿rmthatitisîš¿tfor
use?
Important
IftheanswertoanyofthesequestionsisNO,notedownthedeîš¿cienciesasinstructedin
theInstallationremarks.
Relatedtopics
•Sonarroomrequirementsonpage42
•Installationremarksonpage311
76
381293/A
