Installingthehullunit
4Ifyouwishtoreusetheboxtoholdtheoldhullunit,makesurethatyoukeepallthe
fasteninghardwareusedtosecurethehullunitinthewoodenbox.
5Fastentheliftingtackletothetwoliftingeyebolts(A)onthetopofthehoisting
unitandliftthehullunit(withthetransducerprotection(C)inplace)carefully
outofthetransportationbox.
Important
Usethecorrectliftingeye!
Therearetwoliftingeyesoneachsideofthe
hullunit:oneonthehoistingunitandone
onthetopofthetransducershaft.Makesure
thatyouusetheliftingeyeonthehoisting
unit(A)whenyouliftthehullunitoutof
thetransportationbox!
[_____]Ok
6Makesurethatyoukeepthetransducercable
andconnectordry.Watchthesecarefullyto
preventthemfrombeingdamaged,stuckorhookedontoprotrudingobjectswhile
manoeuvringthehullunitintothesonarroom.
Important
Donotremovethetransducerprotection(thethickfoam)fromthetransduceruntil
justbeforethehullunitisloweredontothemountingtrunk.
[_____]Ok
381293/A
69
