EM500
Open-Loop
V
ector
Control
Inverter
User
Manual
112
DeviceNet
Expansion
Card
F10.14
Response
Delay
Time
of
Process
Data
of
Communication
Card
0.0
-
200.0
ms
0.0
〇
F10.15
Bit
Rate
of
Communication
between
Expansion
Card
and
Bus
Ones
Place:
CANopen
0:
125K
1:
250K
2:
500K
3:
1M
T
ens
Place:
DeviceNet
0:
125K
1:
250K
2:
500K
23
〇
F10.16
PROFIBUS
Communication
Format
0:
PPO1
1:
PPO2
2:
PPO3
3:
PPO4
4:
PPO5
×
F10.17
Received
Data
T
ype
PZD2
When
the
displayed
data
is
65535,
it
means
that
present
PZD
is
not
used.
When
the
displayed
data
is
other
data,
for
example
4609,
it
means
that
the
function
parameter
is
F18.01
(18D=12H,
01D=01H,
1201H=4609D)
65535
〇
F10.18
Received
Data
T
ype
PZD3
65535
〇
F10.19
Received
Data
T
ype
PZD4
65535
〇
F10.20
Received
Data
T
ype
PZD5
65535
〇
F10.21
Received
Data
T
ype
PZD6
65535
〇
F10.22
Received
Data
T
ype
PZD7
65535
〇
F10.23
Received
Data
T
ype
PZD8
65535
〇
F10.24
Received
Data
T
ype
PZD9
65535
〇
F10.25
Received
Data
T
ype
PZD10
65535
〇
F10.26
Received
Data
T
ype
65535
〇
111
113
