EM500 Open-Loop Vector Control Inverter User Manual
262
For communication expansion card address setting, user only needs to set
corresponding function codes to current expansion card.
This function code is used to determine the delay response time of communication
card after master sends data to communication card.
No.
Function
Range
Unit
Default
Type
F10.15
Bit Rate of
Communication between
Expansion Card and Bus
Ones Place: CANopen
0: 125K
1: 250K
2: 500K
3: 1M
Tens Place: DeviceNet
0: 125K
1: 250K
2: 500K
23
〇
When selecting a communication expansion card, CANopen or DeviceNet, user
needs to set the bit rates for the communication between the expansion card and the bus.
No.
Function
Range
Unit
Default
Type
F10.16
PROFIBUS
Communication Format
0: PPO1
1: PPO2
2: PPO3
3: PPO4
4: PPO5
×
When the selected expansion card is Profibus-DP, user needs to set the
communication format. Please refer to the expansion card manual for details
No.
Function
Range
Unit
Default
Type
F10.17
Received Data Type PZD2
When the displayed
data is 65535, it means
that present PZD is not
used.
When the displayed
65535
〇
F10.18
Received Data Type PZD3
65535
〇
F10.19
Received Data Type PZD4
65535
〇
F10.20
Received Data Type PZD5
65535
〇
F10.21
Received Data Type PZD6
65535
〇
No.
Function
Range
Unit
Default
Type
F10.14
Response Delay Time of
Process Data of Communication
Card
0.0 - 200.0
ms
0.0
〇
