EM500 Open-Loop Vector Control Inverter User Manual
263
data is other data, for
example 4609, it means
that the function
parameter is F18.01
(18D=12H, 01D=01H,
1201H=4609D)
F10.17 - F10.31 are used to define the data sent from the communication expansion
card (i.e., received by inverter) and are generally parameter setting; F10.32 - F10.46 are
used to define the data received by the communication expansion card (sent by inverter)
and are generally status parameters. All the exchange data should correspond to these
functions codes or the defined fields of the virtual addresses and not be manually set.
