EM500 Open-Loop Vector Control Inverter User Manual
264
Refer to communication expansion card instructions.All the exchange data correspond to
the function codes or the virtual address definition areas respectively (refer to
Communication Protocol) and user does not need to set them manually. Refer to
corresponding manuals of communication expansion cards.
No.
Function
Range
Unit
Default
Type
F10.47
Communication Card
Status
Ones Place: Profibus-DP
0: Initialization Status
1: Wait for Parameterization
Status
2: Wait for Configuration
Status
3: Data Exchange Status
4: Modbus Communication
Abnormality Status
5: Factory Test Status
Tens Place: CANopen
0: Initialization Status
1: Pre-Operation Status
2: Operation Status
3: Stop Status
4: CANopen
Communication
Abnormality Status
5: Modbus Communication
Abnormality Status
6: Factory Test Status
Hundreds Place:
DeviceNet
0: Initialization Status
1: MACID Detection Status
2: Online Non-Connection
Status
3: Connection Status
4: IO Communication
Overtime Status
5: DeviceNet Bus
Communication
Abnormality Status
000
×
