EM500 Open-Loop Vector Control Inverter User Manual
79
Direct Setting
8: digital Potentiometer
9: Not Used
10: Process PID
11: Simple PLC
F00.06
Frequency Source
Options
0: Main Frequency Source A
1: Auxiliary Frequency Source B
2: Main and Auxiliary Arithmetic
Results
3: Switching between Main Frequency
Source A and Auxiliary Frequency
Source B
4: Switching between Main Frequency
Source A and Main & Auxiliary
Arithmetic Results
5: Switching between Auxiliary
Frequency Source B and Main &
Auxiliary Arithmetic Results
6
：
Auxiliary Frequency Source B+
Feedforward arithmetic
（
Winding
application
）
0
〇
F00.07
Numeric Frequency
Setting
0.00 Hz - Maximum Frequency F00.16
Hz
50.00
●
F00.08
Main and Auxiliary
Arithmetic
0: Main Frequency Source A +
Auxiliary Frequency Source B
1: Main Frequency Source A - Auxiliary
Frequency Source B
2: The Bigger of Main A and Auxiliary
B
3: The Smaller of Main A and Auxiliary
B
0
〇
F00.09
Reference Option for
Auxiliary Frequency
Source B at Main
and Auxiliary
Arithmetic
0: Relative to Maximum Frequency
1: Relative to Main Frequency Source
A
0
〇
F00.10
Main Frequency
Source Gain
0.0 - 300.0
%
100.0
●
F00.11
Auxiliary Frequency
Source Gain
0.0 - 300.0
%
100.0
●
