EM500 Open-Loop Vector Control Inverter User Manual
93
Time
F03.16
R2 Ineffective Delay
Time
0.000 - 30.000
s
0.000
●
F03.17
Y1 Monopulse
Output Time
0.001 - 30.000
s
0.250
●
F03.18
Y2 Monopulse
Output Time
0.001 - 30.000
s
0.250
●
F03.19
R1 Monopulse
Output Time
0.001 - 30.000
s
0.250
●
F03.20
R2 Monopulse
Output Time
0.001 - 30.000
s
0.250
●
F03.21
Analog Output M1
0: Running Frequency (absolute value)
1: Set Frequency (absolute value)
2: Output torque (absolute value)
3: Set Torque (absolute value)
4: Output Current
5: Output Voltage
6: Bus voltage
7: Output power
8: AI1
9: AI2
10: AI3
11: AI4 (Expansion Card)
12: High-Frequency Pulse Input
(100.00% Corresponding to Maximum
Frequency, 0.00% Corresponding to
Minimum Frequency)
13: Not Used
14: The Count Value
15: Length Value
16: The PID Output Percentage
18: PID Feedback
19: PID Given
20~37: Not Used
38: The Fan Speed Output
0
〇
F03.22
Analog Output M2
2
〇
F03.23
Y2 High-Frequency
Pulse Output
Function
11
〇
F03.24
100% Frequency of
Y2 High-Frequency
Pulse Output
0.00 - 100.00
kHz
50.00
●
F03.25
0% Frequency of Y2
High-Frequency
0.00 - 100.00
kHz
0.00
●
