EM500 Open-Loop Vector Control Inverter User Manual
92
64: I pump control
65~66: Not Used
67: Brake Control
68: Material supply disruptions
Detection Output
69: FDT1 Lower Bound (Pulse)
70: FDT2 Lower Bound (Pulse)
71: FDT1 Lower Bound (Pulse JOG Is
Invalid)
72: FDT1 Lower Bound (Pulse JOG Is
Invalid)
F03.05
Output Signal Type
D7
D6
D5
D4
D3
D2
D1
D0
0000
〇
*
*
*
*
R2
R1
Y2
Y1
0: Level
1: Monopulse
F03.06
Positive/Negative
Logic of Numeric
Output
D7
D6
D5
D4
D3
D2
D1
D0
00000
〇
*
*
*
Y3
R2
R1
Y2
Y1
0: Positive Logic, Enabled at
On/Disabled at Off
1: Negative Logic, Disabled at
On/Enabled at Off
F03.07
Y2 Output Type
0: Common Numeric Output
1: High-Frequency Pulse Output
0
〇
F03.08
Output Status
Control at JOG
D7
D6
D5
D4
D3
D2
D1
D0
00000
〇
*
*
*
REV
FDT2
FDT1
FAR
RUN
0: Enabled at JOG
1: Disabled at JOG
F03.09
Y1 Effective Delay
Time
0.000 - 30.000
s
0.000
●
F03.10
Y1 Ineffective
Delay Time
0.000 - 30.000
s
0.000
●
F03.11
Y2 Effective Delay
Time
0.000 - 30.000
s
0.000
●
F03.12
Y2 Ineffective
Delay Time
0.000 - 30.000
s
0.000
●
F03.13
R1 Effective Delay
Time
0.000 - 30.000
s
0.000
●
F03.14
R1 Ineffective Delay
Time
0.000 - 30.000
s
0.000
●
F03.15
R2 Effective Delay
0.000 - 30.000
s
0.000
●
